Description
| Mark | Hikvision |
| Gamma | Value |
| Image sensor | 1/3 "Progressive scan cmos |
| Maximum resolution | 4 megapíxel (2560x1440) |
| Main Stream Rate | 20 FPS (2560x1440), 25 FPS (1920 × 1080, 1280 × 720) |
| Extra stream rate | 25 FPS (1280 × 720, 640x480, 640 × 360) |
| Compression | H.265+ / h.264+ / h.265 / h.264 |
| Bitrate | 32 kbps ~ 8 Mbps |
| Optical | 2.8 mm |
| Vision Angle (FOV) | H: 98 °, V: 54 °, D: 114 ° |
| Dari | 63 m (d), 25 m (o), 12 m (r), 6 m (i) |
| Electronic Shutter | 1/3 ~ 1/100,000 s |
| Minimal lighting | Color: 0.01 lux @(F2.0, AgC On) 0 lux with go |
| Supplementary lighting | Hybrid light: IR and white light Range White light range 30 m |
| Day/night | Mechanical filter ICR removable |
| Image improvements | WDR (120 dB), BLC, HLC, 3D-DNR, AWB, ROI, Mirroring, Privacy Mask |
| Motion detection | Movement detection 2.0 with human classification and vehicle applied to movement detection. |
| Audio | Integrated microphone |
| Audio type | Monkey |
| Audio compression | G.711ulaw/g.711ALAW/G.722.1/G.726/MP2L2/PCM/AAC-LC |
| BITS AUDIO RATE | 64 kbps (g.711 ulaw)/64 kbps (g.711 alaw)/16 kbps (g.722.1)/16 kbps (g.726)/32 to 160 kbps (mp2l2)/16 to 64 kbps (AAC-LC) |
| Network interface | Ethernet 10 /100 Baset |
| Remote access | Web browser, Hik-Connect Smartphone App, PC Software IVMS-4200 and Hik-Central |
| Interoperability | Onvif, Isapi |
| Food | DC 12 V / 400 mA / 5 W Max. / Poe IEEE802.3AF |
| Degree of protection | IP67 Waterproof |
| Material | Metal and plastic |
| Temp. operation | -30º C ~ +60º C |
| Dimensions | 66 mm (AL) x 69.1 mm (LG) x 170.8 mm (FD) |
| Base dimensions | Ø Base 70 mm / Ø Between tornillos 55 mm / 3 tornillos |
| Weight | 270 g |
| Color | Black |
