Description
| Mark | Hikvision |
| Gamma | Value |
| Image sensor | 1/2.8 "Progressive scan cmos |
| Maximum resolution | 4 megapíxel (2560x1440) |
| Main Stream Rate | 20 FPS (2560x1440), 25 FPS (1920 × 1080, 1280 × 720) |
| Extra stream rate | 25 FPS (1280 × 720, 640x480, 640 × 360) |
| Compression | H.265+ / h.264+ / h.265 / h.264 |
| Bitrate | 32 kbps ~ 8 Mbps |
| Optical | 4 mm |
| Vision Angle (FOV) | H: 82 °, V: 45 °, D: 98 ° |
| Dari | 53 m (d), 21 m (o), 10 m (r), 5 m (i) |
| Electronic Shutter | 1/3 ~ 1/100,000 s |
| Minimal lighting | Color: 0.01 lux @(F2.2, AgC ON) 0 lux with go |
| Supplementary lighting | Hybrid light: IR and white light Range go 20 m White light range 15 m |
| Day/night | Mechanical filter ICR removable |
| Image improvements | DWDR, BLC, HLC, 3D-DNR, AGC, AWB, ROI, mirror function, privacy mask |
| Motion detection | Movement detection 2.0 with human classification and vehicle applied to movement detection. |
| Audio | Integrated microphone |
| Audio type | Monkey |
| Audio compression | G.711ulaw/AAC-LC |
| BITS AUDIO RATE | 64 kbps (g.711ulaw)/16 to 64 kbps (AAC-LC) |
| Network interface | Ethernet 10 /100 Baset |
| Remote access | Web browser, Hik-Connect smartphone application, PC IVMS-4200 software |
| Interoperability | Onvif (profile s, t), Isapi, sdk |
| Food | DC 12 V / 420 MA / 5 W Max. Poe IEEE802.3AF |
| Degree of protection | IP67 Waterproof |
| Material | Plastic |
| Temp. operation | -30º C ~ +45º C |
| Dimensions | 57.9 mm (AL) x 60.9 mm (LG) x 138.8 mm (FD) |
| Base dimensions | Ø Base 70 mm / Ø Between tornillos 55 mm / 3 tornillos |
| Weight | 175 g |
Opinions of our customers
Do you have or have you used the product?
Post comment
Details
SKU
DS-2CD1041G2-LIU(4mm)
EAN
6942160461793
Categories
Manufacturer
