Description
| Mark | X-security |
| Maximum resolution | 4 megapixel (2560 × 1440) |
| Image sensor | 1/2.9 ”Progressive CMOS |
| Lens | 2.7 mm–13.5 mm (h: 104 ° –29 °; V: 54 ° –16 °; D: 125 ° –34 °) |
| Range | 60 m |
| Main Stream Rate | 2688 × 1520@(1–20 fps)/2560 × 1440@(1-25/30 fps) |
| Extra stream rate | 704 × 576@(1–25 fps)/704 × 480@(1–30 fps) |
| Compression | H.265; H.264; H.264h; H.264B; MJPEG |
| Dari | 64-210 (D), 25.6-84 (O), 12.8-42 (R), 6.4-21 (I) |
| Minimal lighting | 0.006 lux@f1.5 (color, 30 IRE) 0.0006 lux@f1.5 (B/W, 30 IRE) 0 lux (linked illuminator) |
| Image improvements | WDR 120 DB, BLC, HLC, AWB, AGC, 3D-NR, ROI, Smart IR |
| SIV (perimeter protection) | Intrusion, Tripwire (both functions support the precise classification and detection of vehicles and people) |
| Intelligent research | Work together with Smart NVR to improve smart research, event extraction and fusion with event videos |
| Network interface | Ethernet 10/100 Baset |
| Audio | Incorporated microphone |
| Audio compression | G.711A; G.711MU; PCM; G.726 |
| Remote access | Web Interface, CMS (DSS/PSS), Smartphone and NVR |
| Material | Metal |
| Interoperability | Onvif (profile without profile t); CGI |
| Food | DC 12 V / 3.1W, POE IEEE802.3AF |
| Color | Black |
| Temp. operation | -30º C ~ +60º C |
| Degree of protection | IP67 Waterproof, IK10 Antivandalism |
| Dimensions | 238.5 mm (FO) x 90.7 (Ø) mm |
| Weight | 730 g |
Opinions of our customers
Do you have or have you used the product?
Post comment
Details
SKU
XS-IPB830ZSWH-4P-AI-BLACK
EAN
8435325474793
