Description
| Mark | X-security |
| Image sensor | 1/29 ”Progressive CMOS |
| Maximum resolution | 4 megapixel (2688x1520) |
| Lens | 2.7 ~ 13.5 mm (h: 104 ° –29 ° V: 54 ° –16 ° D: 125 ° –33 °) |
| Dari | 64-210 (D), 25.6-84 (O), 12.8-42 (R), 6.4-21 (I) |
| Main Stream Rate | 2688 × 1520 @ (1–25/30) FPS |
| Extra stream rate | Sub-Stream 1: 704 × 576 @ (1–25 fps)/704 × 480 @ (1–30 fps) Substream 2: 1920 × 1080 @ (1–25/30 fps) |
| Compression | H.265; H.264; H.264h; H.264B; MJPEG (compatible with substance only) |
| Smart codec | Smart H.265+ Smart H.264+ |
| AI coding | Ai H.265 Ai H.264 |
| Minimal lighting | 0.005 lux@f1.5 (color, 30 IRE) 0.0005 lux@f1.5 (black and white, 30 iRE) 0 lux (linked illuminator) |
| SIV (perimeter protection) | Tripwire, intrusion (support for precise classification and detection of vehicles and people); |
| Ai SSA (Ai Scene Selfadaptation) | Yes |
| Intelligent research | Work together with Smart NVR to improve smart research, event extraction and fusion with event videos |
| SMD 4.0 | Yes |
| Image improvements | WDR 120DB, BLC, HLC, AWB, AGC, 3D-NR, ROI, Smart IR |
| Day / night | Mechanical filter ICR removable |
| Network interface | Ethernet 10/100 Baset |
| Material | Metal |
| Remote access | Web Interface, CMS (DSS/PSS), Smartphone and NVR |
| Interoperability | Onvif (Profile S/Profile G/Profile T); .CGI; P2P; March; Genetec |
| Food | DC 12 V / 3.6 W, Poe IEEE802.3AF |
| Temp. operation | -30º C ~ +60º C |
| Degree of protection | IP67 Waterproof, IK10 Antivandalism |
| Dimensions | 94 mm (FO) x 122 (Ø) mm |
| Weight | 713 g |
