Description
| Mark | Hikvision |
| Gamma | Value |
| Image sensor | 2 MPX CMOS |
| Maximum resolution | 1080p (1920x1080) at 30 fps |
| Resolution | TVI: 1080p (25 ~ 30 fps) CVI: 1080p (25 ~ 30 fps) AHD: 1080p (25 ~ 30 fps) CVBS: PAL/NTSC |
| Lens | 2.8 mm |
| Vision Angle (FOV) | 101º (h), 60º (v), 122º (D) |
| Minimal lighting | 0.01 lux @ (F2.0, AgC ON) |
| Infrared lighting | 0 lux / (IR Smart of reach 20 m) |
| Day / night | Auto / color / black and white (ICR) |
| Video output | 1 x BNC Commutable HDTVI / HDCVI / AHD / CVBS |
| Video Output Switching | Through switch |
| Basic functions | Menu Osd (remote) |
| ASD Functions Configurable | DWDR, BLC, HLC, AGC, AWB, Smart IR |
| Communication | HIKVIS-C |
| Positioning Lens | 3 Axis |
| Food | DC 12 V / 1.8 W Max. |
| Degree of protection | Interior |
| Temp. operation | -40º C ~ +60º C |
| Material | Plastic |
| Dimensions | Ø 98 mm x 65.4 mm (AL) |
| Weight | 146 g |
Opinions of our customers
Do you have or have you used the product?
Post comment
Details
SKU
DS-2CE56D0T-IRMMF(2.8mm)(C)
EAN
6941264014096
Categories
Manufacturer
