Description
| Mark | Hikvision |
| Gamma | Value |
| Image sensor | 2 MPX CMOS |
| Maximum resolution | 1080p (1920x1080) at 30 fps |
| Resolution | TVI: 1080p (25 ~ 30 fps) CVI: 1080p (25 ~ 30 fps) AHD: 1080p (25 ~ 30 fps) CVBS: PAL/NTSC |
| Lens | 2.8 mm |
| Vision Angle (FOV) | 105º (h), 56º (V), 126º (D) |
| Minimal lighting | 0.001 lux @ (F1.0, AgC ON) 0 lux with white light, range 40 m |
| Supplementary lighting | Hybrid light: Give range 40 m White light range 40 m |
| Video output | 1 x BNC Commutable HDTVI / HDCVI / AHD / CVBS |
| Video Output Switching | Through switch |
| Basic functions | Menu Osd (remote) |
| ASD Functions Configurable | DWDR, Blc, HLC, 3DNR/2DNR, AGC, AWB, Smart Light |
| Audio | Integrated microphone Coaxial audio |
| Communication | HIKVIS-C |
| Positioning Lens | 3 Axis |
| Food | DC 12 V / 4.2 W Max. |
| Degree of protection | IP67 Waterproof |
| Temp. operation | -40º C ~ +60º C |
| Material | Body: Metal Cover: Plastic |
| Dimensions | Ø 110 mm x 98.3 mm (AL) |
| Base diameter | Ø Base 110 mm / Ø Between tornillos 85 mm / 3 tornillos |
| Weight | 320 g |
Opinions of our customers
Do you have or have you used the product?
Post comment
Details
SKU
DS-2CE72DF0T-LFS(2.8mm)
EAN
6931847198596
