Liquid Freezer III 360 ARTIC
Description
Liquid Freezer III 360 ARTIC
Arctic Water Cooler CPU Liquid Freezer III 360 All-in-One Black
Product Details
Easy Installation The Liquid Freezer III is ready to be used immediately thanks to pre-installed radiator fans in the push configuration. The fans cables are integrated into the hoses coating, so it is only necessary to connect a cable to the motherboard. With the MX-6 thermal compound included in delivery, it has everything you need for a quick and easy installation. Future proof compatibility Liquid freezer III is multi-compatible with sockets Intel and AMD. Intel will launch the new Arrow Lake processors at Socket LGA1851 in the future. Arctic customers do not need to worry about the fact that new CPUs also require new refrigerators. We guarantee complete compatibility. All Liquid freezer III can be used with Intel's new LGA1851 socket without limitations. Silent VRM converter VRM converters of the motherboards often work at their maximum temperature in combination with a lot of energy. To compensate for the lack of airflow of a tower cooler, Liquid Freezer III works with a VRM magazine fan. The 60mm PWM -controlled fan allows almost silent cooling of the socket area when VRM cooling is insufficient in cases of disabled air flow or especially in overclocking scenarios. This allows a continuously higher load and a longer service life for voltage converters. Intel LGA1700 and LGA1851The independent loading mechanism (ILM) of Intel Deformation to CPU by pressing it to two points over 40 kg. This causes pressure on the PCB, the matrix and welding layer between the matrix and the IHS (Integrated Heat Spreader). With a high thermal load, this can lead to long -term problems. The arctic -pending mounting structure does not deform the CPU, greatly reduces the mechanical load in the CPU, is fast and easy to install and allows the cooler to be bolted on the CPU rear plate. As a result, the mechanical stress on the main plate and the CPU is minimized, the cooling performance remains consistent and the installation is rapid and uncomplicated. Elevated static appeal is based on proven P fans, which have already received several awards for their excellent performance. The P series is particularly suitable for use in heat dissipping and radiators with a high density of alhetas. Thanks to their high static pressure, they get significantly better results compared to the fans designed for high air circulation.
Character
Performance
- Pump engine speed (max.)2800 RPM
- Pump engine speed (min.)800 rpm
- Fan speed (max.)1800 rpm
- Fan Speed (Min.)200 RPM
- Operating Temperature (T-T)0 - 40 ° C
- Bearing typeFluid dynamic bearing (FDB)
- Quantity per set1 unit (s)
- Compatible with pulse width modulation (MLP)
- Pump connector4-Pin
- Static Pressure of the Fan2.2 mmH2O
- TypologyAll-in-One liquid refrigerator
- VRM (max) fan velocity (max)2500 rpm
- VRM Fum Speed (Min.)400 rpm
- Airflow95.65 m³/h
- Size12 cm
- SocketIntel LGA1851, LGA 1700, SOCKET AM4, AM5
- Proper locationProcessor
- Maximum air flow56.3 cfm
Design
- Fan connector4-Pin
- Radiator materialAluminum
- ColorBlack
- Typology3 fan (s)
- Base plate materialCopper
Packaging content
- TypeHanging box
Energy management
- Pump voltage12 V
- Pump current350 mA
- Fan tension12 V
- Fans stream0.1 to
Weights and dimensions
- Radiator length12 cm
- Radiator width39.8 cm
- Radiator height3.8 cm
- Tube length45 cm
- Length0.0400 m
- Dimensions of the fan (C x L x a)120 x 120 x 25 mm
- Inner tube diameter6 mm
- Pump width9.1 cm
- Pump depth10.8 cm
- Pump height6.85 cm
- Packaging Depth414 mm
- Packaging height142 mm
- Packaging length167 mm
- Package weight2.38 kg
- Weight1.84 kg
- Tube diameter1.24 cm
