Raythink Speed Dome bi -Spectrum Pd2 Series - Thermal Sensor 256x192 Vox Uncofated 12μm - Thermal Sensitivity ≤40mk@25 ° C, F#1.0,25Hz - Visible Sensor 1/2.8 "5MPX CMOS - Thermal Lens 10mm - Visible Lens 5.4 ~ 108mm (zoom 20x))
€1,339.54
(IVA included)
€1,089.05
(Without IVA)
Description
| Mark | Raythink |
| Gamma | PD2 |
| Thermal sensor | 256x192 Vox not cooled 12μm |
| Spectral strip | LWIR 8 ~ 14μm |
| Thermal sensitivity | ≤40mk (@25 ° C, F#1.0.25Hz) |
| Optical sensor | 1/2.8 "CMOS 5MPX |
| Lens | 10mm (termin.) / Motorized automatic focus 5.4 ~ 108mm (opt.) 20x |
| PAN/TILT INTERVAL | Horizontal: 360 ° continuous, vertical: 0 ° ~ +90 ° |
| Manual speed | Horizontal: 0.1 ~ 120 °/s, vertical: 0.1 ~ 60 °/s |
| Intelligent Functions | Fire detection Intrusions Detection: Line crossing, area entry CLASSIFICATION MAN/VEHICLE BY IA |
| Temperature range | -20ºC ~ 550ºC |
| Temperature accuracy | ± 2ºC / ± 2% |
| Temperature measurement | Supports up to 4 measurement rules: entire screen, point, line, area |
| Audio | 1 input / 1 output / altifier |
| Alarm | 2 INPUTS / 1 OUTPUT |
| Internal storage | Micro SD card up to 256GB (not included) |
| Network interface | 1x Ethernet 10/100m baset |
| Others | RS485 |
| Interoperability | ONVIF, SDK |
| Food | 12VDC / 20W |
| Temp. operation | -40ºC ~+70ºC |
| Degree of protection | IP66 Waterproof |
| Dimensions | 265 × 147.5 × 248.7 |
| Weight | 2.5 kg. |
