Relay DPDT 24VDC 8a Finder 40.52.9.024.0000
€9.43
/Un
(IVA included)
€7.67
/Un
(Without IVA)
Delivery cost is not included
Description
Relay DPDT 24VDC 8a Finder 40.52.9.024.0000
Manufacturer: Finder
Relay Type: Electromagnetic
Contact Configuration: DPDT
Nominal Coil Voltage: 24V DC
Contact capacity AC @r (in resistance load): 8A / 250V AC
DC @r contact capacity (resistance load): 8A / 30V DC
Max. Contacts: 15th
Switching voltage: max. 220V DC, Max. 400V AC
Relay version: Miniature
Assembly: Base, PCB
Bobin Resistance: 320 ohm
External dimensions: 29x12.4x25mm
Power consumption by the coil: 1.2Va
Operating Temperature: -40ºC ...+85ºC
Relay Series: 40.52
Contact Material: AGNI
Connection Raster: 5mm
Roil Chain: 45MA
