Shelly 1 Gen3 - WiFi Automation Switch Module 110/240VAC 12VDC 24-48VDC - 16A
€16.00
(IVA included)
€13.01
(Without IVA)
Delivery cost is not included
Description
WiFi -controlled relay switch module, 1 channel, 16a AC (max. 240VAC) or 10A DC (max. 30VDC).
Shelly 1 Gen3 is a small -shaped smart (free of potential) contacts, which allows remote control of electrical appliances through a mobile phone, tablet, PC or domotic system.
It allows to control, from anywhere, a wide range of appliances and office equipment (lights, outlets, safety systems, heating radiators, air conditioning, etc.), as well as garage gates, irrigation system, etc.
Shelly 1 Gen3 can be accessed, remotely controlled and monitored from anywhere where the user has an internet connection as long as the device is connected to a Wi-Fi router and the internet.
Combine it with other smart devices of your Smarthome! Configure Shelly 1 Gen3 to activate personalized scenes based on time, sunlight, doors opening, etc. Or automate your garage door and control it through your mobile phone! It can work at 12VDC or 24-48VDC and has dry contact, which makes it perfect for this purpose.
In addition to being able to operate through cloud domotic services, it can also work autonomously on a local Wi-Fi network. It has an incorporated web interface that can be used to monitor and control the device as well as to adjust your settings.
It can be installed in normal electric wall boxes, behind current outlets and light switches or other locations with limited space.
Compared to its predecessor, this new version (Gen3) has an improved processor, higher memory capacity and more resistant terminals. In addition, it also supports the KNX protocol, an open standard Open for automation of buildings that allows communication between intelligent devices such as lighting and climate control of different manufacturers.
SPECIFICATIONS:
◾ Electric
- Food:
· 110-240v AC
· 12c dv
· 24-48V DC
- Energy consumption: <1.2 W
- Contact characteristics:
· Dry contact: yes
· Maximum switching voltage AC: 240 V ~
· Maximum switching voltage DC: 30 V⎓
· Maximum switching current AC: 16 A (@ 240V ~)
· Maximum switching current DC: 10 A (@ 30V⎓)
- Sensors, meters:
· Internal temperature sensor: yes
◾ Wireless connectivity
- Wi-Fi
· Protocol: 802.11 b/g/n
· RF Band: 2401 - 2483 мhz
· Maximum RF power: <20 dbm
· Range: up to 30m in interiors and 50m in outer (depends on local conditions)
· Range Extender: Yes
- Bluetooth
· Protocol: 4.2 with Ble
· Gateway: Yes
· RF Band: 2400 - 2483.5 MHz
· Maximum RF power: <4 dbm
· Range: up to 10m in interiors and 30m in outer (depends on local conditions)
◾ Microcontroller
-CPU: Esp-Shelly-C38F
- Flash: 8MB
◾ Firmware capabilities
- Schedules: 20
- Webhooks (URL actions): 20 with 5 URLs per hook
- Scripting: Yes
- MQTT: Yes
◾ Environmental
- Working temperature: -20 ° C to 40 ° C
- Humidity: 30 % to 70 % rh
- Maximum altitude: 2000 m
◾ Physical
- Assembly: Inside the apparatus box
- Cross -sectional section of the driver: 0.2 to 2.5 mm² / 24 to 14 AWG
- Maximum torque of screw terminals: 0.4 nm
- BOX MATERIAL: Plastic
- Box color: blue
- Terminal Color: Black
- Weight: 26 g
- Size (Axlxp): 37x42x16
Shelly 1 Gen3 is a small -shaped smart (free of potential) contacts, which allows remote control of electrical appliances through a mobile phone, tablet, PC or domotic system.
It allows to control, from anywhere, a wide range of appliances and office equipment (lights, outlets, safety systems, heating radiators, air conditioning, etc.), as well as garage gates, irrigation system, etc.
Shelly 1 Gen3 can be accessed, remotely controlled and monitored from anywhere where the user has an internet connection as long as the device is connected to a Wi-Fi router and the internet.
Combine it with other smart devices of your Smarthome! Configure Shelly 1 Gen3 to activate personalized scenes based on time, sunlight, doors opening, etc. Or automate your garage door and control it through your mobile phone! It can work at 12VDC or 24-48VDC and has dry contact, which makes it perfect for this purpose.
In addition to being able to operate through cloud domotic services, it can also work autonomously on a local Wi-Fi network. It has an incorporated web interface that can be used to monitor and control the device as well as to adjust your settings.
It can be installed in normal electric wall boxes, behind current outlets and light switches or other locations with limited space.
Compared to its predecessor, this new version (Gen3) has an improved processor, higher memory capacity and more resistant terminals. In addition, it also supports the KNX protocol, an open standard Open for automation of buildings that allows communication between intelligent devices such as lighting and climate control of different manufacturers.
SPECIFICATIONS:
◾ Electric
- Food:
· 110-240v AC
· 12c dv
· 24-48V DC
- Energy consumption: <1.2 W
- Contact characteristics:
· Dry contact: yes
· Maximum switching voltage AC: 240 V ~
· Maximum switching voltage DC: 30 V⎓
· Maximum switching current AC: 16 A (@ 240V ~)
· Maximum switching current DC: 10 A (@ 30V⎓)
- Sensors, meters:
· Internal temperature sensor: yes
◾ Wireless connectivity
- Wi-Fi
· Protocol: 802.11 b/g/n
· RF Band: 2401 - 2483 мhz
· Maximum RF power: <20 dbm
· Range: up to 30m in interiors and 50m in outer (depends on local conditions)
· Range Extender: Yes
- Bluetooth
· Protocol: 4.2 with Ble
· Gateway: Yes
· RF Band: 2400 - 2483.5 MHz
· Maximum RF power: <4 dbm
· Range: up to 10m in interiors and 30m in outer (depends on local conditions)
◾ Microcontroller
-CPU: Esp-Shelly-C38F
- Flash: 8MB
◾ Firmware capabilities
- Schedules: 20
- Webhooks (URL actions): 20 with 5 URLs per hook
- Scripting: Yes
- MQTT: Yes
◾ Environmental
- Working temperature: -20 ° C to 40 ° C
- Humidity: 30 % to 70 % rh
- Maximum altitude: 2000 m
◾ Physical
- Assembly: Inside the apparatus box
- Cross -sectional section of the driver: 0.2 to 2.5 mm² / 24 to 14 AWG
- Maximum torque of screw terminals: 0.4 nm
- BOX MATERIAL: Plastic
- Box color: blue
- Terminal Color: Black
- Weight: 26 g
- Size (Axlxp): 37x42x16
