Description

Control and measure the energy consumption of a wide range of appliances and office equipment (lights, sockets, electrical circuits, safety systems, heaters, etc.) from anywhere and/or automatically, with smart actions and scenarios.

The Wave 1 PM works with voltages of 110-240v AC or 24-30V DC and has a contact that supports currents up to 16A which makes it perfect for control and monitoring the consumption of high power electrical appliances.

This module, from the Shelly Qubino series, works with Z-Wave and can communicate perfectly with other devices that use this technology, regardless of your brand or platform, but it takes a centralized smart hub.

Wave 1 PM is designed to be installed behind any switch or taking it, transforming it instantly into a smart device. Once installed, include it on your Z-WAVE network and control the light-bound lights or devices from anywhere, using your smartphone or tablet. Shelly Qubino devices work with over 4000 Z-Wave Gateways and Gateways.

Once configured it can establish direct communication with other Z-Wave devices and perform some personalized actions without the presence of a hub! It also allows you to create personalized schedules aligned with your daily routine or synchronize actions with sunrise/sunset to manage your lighting or create custom scenarios, but it takes a gateway.

Features:
● Energy measurement
● Extremely low energy consumption: 0.3 W
● Newer technology: Z-Wave 800 Series
● Z-Wave frequency band: 868.4 MHz (CEPT countries)
● Automatic configuration with smartstart
● Authenticated for the highest level of security (S2)
● Supports OTA firmware updates (Over-The-Air)
● Simple installation on most standard electric boxes and switches
● Works with Z-Wave certified gateways and more than 4,000 Z-Wave devices

SPECIFICATIONS
-Food: 110-240V AC / 24-30V DC
- Energy consumption: <0.3 W
- Contact:
· Potential free (dry contact): No (linked to the phase)
· Maximum voltage / current of switching AC: 240V / 16 A
· Voltage / maximum switching current DC: 30V / 10 A
- Power and energy measurement: yes
-CPU: Z-WAVE ™ S800 (System-in-Package)
- Z-WAVE COMMUNICATION:
· Frequencies: Under-G (from 868.4 to 920.9 MHz)
· Z-WAVE ™ repeater: yes
· Range: up to 40m in interior spaces (depends on local conditions)
- Protection against overheating: yes
- Overload Protection: Yes
- Driver cross section: 0.5 to 1.5 mm² (20 to 16 AWG)
- Enclosure material: Plastic
- ambient temperature: -20 ° C to 40 ° C
- Humidity: 30% to 70% hr
- Color: Red
- Weight: 27 g
- Size (a x l x p): 37x42x16 ± 0.5 mm

IMPORTANT:
◾ To configure this device and use all its features, a gateway or Smart Hub with Z-Wave connectivity (not included) is required.
◾ This device does not work with the Shelly App application, to configure/control it, you will have to use the specific application for the gateway you want to use.
