Switch Poa White Brand - Carril Din Assembly - 8 Gigabit Doors + 2 SFP Gigabit - 90W Doors 1 Y 2 / 30W 3-8 / maximum 240W - IEEE802.3AF / AT / BT | Poe/Poe+/Hi -POE - VLAN/STP/RSTP/MSTP/ERPS/SNMP/ACL - Static Lag/IGMP Snooping/DHCP Snoop/802.1x
€278.11
(IVA included)
€226.11
(Without IVA)
Delivery cost is not included
Description
| Interface | 8 ports RJ45 gigabit + 2 doors SFP gigabit |
| POE CHARACTERISTICS | Up to 90W Doors 1 and 2 IEEE802.3BT HI-POE Up to 30w doors 3-8 IEEE802.3AF/AT POE/POE+ Maximum 240W |
| Expanded po | Up to 250m The door must be forced at 10Mbps. |
| Supported Topologies | Ring / Star / Bus / Tree |
| Physical Cover Protocols | MDX/MDIX/Flow Control |
| Network protocols | VLAN/STP/RSTP/ERPS/SNMP/IGMP Snooing/802.1x/Port isolation/Qinq |
| Management Protocols | SNMP/CLI/CONSOLA/WEBUI/SSH/TELNET/RMON |
| Quality of service | Priority rescheduled and mapping Supports SP and WRR algorithms Boundary QoS based policies |
| Connection aggregation | Up to 12 groups |
| Jumbo Frame | 10kbyes |
| ACL | Supports 500 standard and extended ACLs |
| Switching capacity | 36gbps |
| Mac table | 16K |
| Package referral rate | 26.78Mbps |
| Buffer | 12m |
| Installation | Din gutter |
| Food | DC 48 V ~ 58 V - Power supply not included. The following references are recommended: - DC48V5A-DIN - DC48V2A-DIN |
| Dimensions | 48 (FO) X 104 (AL) X 143 (AN) MM |
| Weight | 580 g |
| Operating temperature | -40º C ~ 75º C |
